9

WWW.7X24EXCHANGE.ORG

Education Center adjacent to the

hospital’s main campus. The new

building, which can withstand a

Category 5 tornado, includes a new

server room and data center, a

customized standby power

generation system, the IT

department, administrative offices

and a clinical research area.

“When designing the Tech and Ed

Center, we put a lot of thought into

energy efficiency. We looked at

power systems, chill beams, rack

coolers, heat pumps and other

features, but we also implemented

ways to recover as much of that

energy as we could,” explained

Johanson. “We’re using the waste

heat from IT to heat the building,

which cuts energy load

tremendously. It’s working better

than expected as it only costs 40

percent of what it takes to heat the

main campus.”

The new facility is built with a variety

of energy efficiencies to help cut

costs, improve sustainability and

reduce environmental impact. In fact,

the new building costs $1.48 per

square foot in energy each year

compared to $2.84 per square foot

at the main campus. To achieve this,

the hospital implemented an

effective energy strategy.

ENERGY EFFICIENCIES

The latest industry trends indicate

system efficiency is the top priority

when it comes to building data

centers. Companies are applying

energy-conscious design strategies

to eliminate as much waste as

possible. No detail is too small as

building materials, storage

components, heating, use of space,

maintenance needs, security, wire

routing, cooling systems, piping and

even elevators are thoroughly

considered.

CHI St. Alexius Health worked with

the local Cat

®

dealer, Butler

Machinery, to design a customized

backup power system including six

Cat C15 500 kW standby diesel

generator sets with Cat Engine

Paralleling and Integration Controls

(EPIC), and two Cat Flywheel

Uninterruptible Power Supply (UPS).

Three custom enclosures were

designed with two generator sets

each, arranged side by side, to

overcome space constraints and

ease of maintenance concerns.

“A reliable standby power system is

crucial to CHI St. Alexius Health. It

serves our administrative offices,

financial department and most

importantly, our data center,”

explained Johanson. “We worked

closely with Butler Machinery to

design a fully integrated system, and

we ended up with an intricate setup

that utilizes multiple flywheels,

several generator sets, and an A and

B electrical feed, so we’re never

without power.”

Butler Machinery aligned with the

long-term vision at the hospital by

providing a cost-effective solution

that maintains quality. Capable of

accepting 100 percent rated load in

a single step, the C15 engines offer

proven performance and optimized

fuel economy. The remote-mounted

EPIC system eliminates the need for

traditional hard-wired components

and manages the generator sets

while seamlessly directing power

through the distribution switchgear.

Providing constant power protection,

the flywheel UPS insulates the

generator sets from transient and

block loads, and provides operating

efficiencies that exceed traditional

battery-type UPS.

Beyond the power system, the

hospital also incorporated advanced

energy efficiencies into the

Technology and Education Center

infrastructure. These features

include:

• GEOTHERMAL SYSTEM

– Heat

generated by the data center is

used to heat the building with a

geothermal recovery design. A

pump pulls water from 302

underground wells, which flows

through pipes around the building.

Waste heat from the data center

increases the water temperature

and then distributes warmth to

other parts of the building. The

process is reversed in the summer

to cool the facility, making it a very

efficient and cost-effective feature.

• CHILLED BEAMS

– Heat/cool coil

units, or chilled beams, take

outside air with recovery reels to

regulate temperature in the

building. Only one air handling unit

is required to support the new

facility compared to the 13 units

needed to manage the main

campus, thus reducing duct work,

We’re not looking

10 or 20 years

down the road.

We’re planning for

the next 100 years,

which is reflected

in the way

we designed...
