underfloor issues result in increases

in hot air re-circulation over the tops

of cabinets or around the ends of

cabinet rows. a common response to

address high it equipment intake

temperatures is to increase cooling

airflow volume or reduce

temperature setpoints.

often ignored ΔT:

exhaust back to

Cooling unit

(#2 in Figure 1)

in contemporary data centers, the Δt

from servers back to the cooling

source is usually negative; the

temperature of the return air tends

to decrease after it is exhausted from

the it equipment as it makes its way

back to be re-cooled. this makes

sense, as the excess cooling air is

bypassing the data center heat load

and returning to the cooling units,

reducing the temperature of the

return air along the way. there are

several causes of such bypass

airflow:

• improperly located perforated floor

tiles that can cause cool air to

bypass the heat load.

• large underfloor pressure

differentials which may result in

high pressure zones that pump

significant quantities of air into a

cold aisle in excess of the demand

indicated by the intake fans of the

associated it equipment.

• unsealed cable access holes in tiles

located toward the rear of server

racks that will result in cold air

joining the exhaust air inside the

back of the server rack. this source

of bypass airflow can be especially

troublesome when managing

cooling efficiency issues via Δt’s, as

it can mask the true it equipment

Δt. before monitoring or taking

corrective action in response to this

Δt, plug any holes in the unsealed

floor cut-outs in the rear of server

racks to help eliminate false

measurements.

RemeDial

ConsiDeRaTions

when server inlet temperature is

more than 5˚f above the supply

temperature being produced by

cooling units, there is hot air re-

circulation occurring from open

pathways between a hot and cold

aisle, inside or around the server

racks, or an inadequate flow zone

that may require Cfd analysis to

determine the source of pressure

variations under the floor. if the

return air intake of the cooling units

are more than 5˚f lower than the

exhaust temperature from the it

equipment, there is a bypass airflow

problem. areas to check include

improperly placed floor tiles,

unsealed floor openings, or simply

excess airflow being delivered into

the room.

these 5˚f guidelines for calibrating

Δt’s are only suggestions to help

increase the efficiency of the data

center. the overall goal (particularly

if free cooling is available) is to get

the differentials between the server

exhaust and the cooling unit return

intake and between the cooling unit

supply and the server intake as close

to zero as possible. that alignment

will result in a better harmonization

between expenses made for cooling

and the true cooling work required.

it will also increase opportunities for

more free cooling hours if free

cooling is part of the data center’s

design.

in most circumstances, optimum

efficiency in the data center will be

achieved when:

• there is minimal difference

between the supply air

temperature and the server inlet

temperature (#4 in figure 1).

• there is minimal difference

between the it equipment Δt and

the cooling coil Δt (#1 and #3 in

figure 1).

• the supply temperature can be

elevated to a temperature

approximating the maximum

specified upper threshold for the

space (once the above two

conditions are met).

Monitoring all four Δt’s can provide

valuable information for calibrating

the data center to meet its ideal

performance level, regain stranded

capacity and reduce operating cost.

Lars Strong is Senior Engineer of Upsite Technologies. He can he reached at

[email protected]

Ian Seaton is Technical Advisor to Upsite Technologies. He can he reached at

[email protected]

¹ There will be some conditions in which the ΔT will not remain constant, especially with the proliferation of variable speed fans in IT equipment.

When inlet temperatures are allowed to exceed the maximum recommended threshold and move toward the upper allowable levels, many servers

will increase fan speeds to protect equipment, thereby reducing the ΔT through the IT equipment. Additionally, with the increased adoption of

cloud-based data centers, large caches of work can be transferred between data centers with the resultant increased work load producing higher

chip temperatures and, therefore, higher ΔT’s. Nevertheless, in normal conditions, the equipment ΔT remains a constant.

²http://www.upsite.com/blog/equipment-delta-t-flow-rate-impact-data-center
