8

1

silicon realities. this first Guiding principle

addresses

reliability, maintainability, functionality,

flexibility and a robust system architecture.

this principle established design parameters early on

that directly resulted in an established basis of design

and increased collaboration since the building layout

took shape with the contractor at the table in the early

design phase. similarly, when it came to designing the

data center’s cabinet layout, reliability and functionality

were key. therefore, Cps energy and syska’s team

required that a physical mockup of a typical row of

cabinets be created. this mockup included the full

complement of infrastructure, including the back-of-

rack cooling solution, overhead busways, cable tray

and lighting so Cps energy could see what their

system would look like and how these individual

components would all be accessible between each row

of cabinets. again, this helped eliminate questions and

future operational maintenance issues in the field.

to build in flexibility for future expansion on site, syska

designed an Mep/it infrastructure that would be ready

for a phase ii build out, with the ability to expand the

building for additional cabinets and utilize existing

back of house spaces to accommodate an additional

generator, ups, chillers, and piping, etc. to support

phase ii. the goal was to preserve the ability to

expand while minimizing the impact to ongoing

whitespace operations.

increased efficiency and reliability were established at

eCho by eliminating the raised floor and replacing

traditional computer room air conditioner (CraC) units

with a refrigerant based back-of-rack cooling solution.

with no raised floor, the epo system could be

eliminated. instead of traditional CraC units

supporting the whitespace, pumped refrigerant units

were installed in galleries adjacent to the space,

keeping all chilled water piping located outside of the

critical spaces.

2

Carbon Creature Comforts. this Guiding

principle tackled

consistency, survivability,

daylighting and a softened security experience.

eCho’s control rooms are a case in point for this

Guiding principle. together, syska’s Mep/technology

team and the architects at Corgan associates began

control room design by defining how many operators

would be working in the areas, which led to deciding

how large the space would be, how many display

screens, size of screens and ultimately, the owner’s

requirements for low-voltage systems. syska’s

Mep/technology team utilized 3d modeling software

to fine-tune control room designs, which resulted in a

recessed well in the operator consoles to

accommodate desired sightlines and an articulated

monitor mounting solution that could pivot at the top

and bottom to enable control room operators to see

beyond their own monitors onto the main display wall

screens. this process was critical to meeting the

operator’s requirements while optimizing the design

and coordination of architectural lighting, Mep and

technology.

while the facility is a mission critical control/data

center, Cps energy made it a priority to create a

positive human interface for those working inside. for

example, a floor path between the two control rooms

was created with artwork and creative lighting and

ergonomic desks were specified for employees. one of

the biggest design challenges was to segregate the

two control rooms per federal regulations — with a six-

wall separation. how can a working separation be

maintained while not duplicating areas that could be

deemed common space? to achieve the separation

between different function areas, the design team

worked closely with Cps energy’s project committee

members and project Manager bill badger, who was

responsible for coordinating the needs of each group.

the results of this coordination allowed for efficient

floorplan design without duplication of common use

space. a successful space plan for facilities such as

eCho requires a commitment from the owner to

actively be involved with the design team, including

decision makers during the design process.

7X24 MAGAZINE FALL 2015

the charrette set the tone for eCho by establishing four Guiding principles that would serve as the foundation for

the basis of design documents. these principles streamlined the efforts of building team members from design to

construction and post-occupancy, ultimately ensuring that the original objectives were met in the final facility.
