INTRODUCTION

The process of commissioning is

often viewed as validation of

components and systems only. Done

right, commissioning is a

comprehensive integration process

that includes not only the physical

infrastructure but also the people who

will operate the facility.

Data Center construction and

operations are often managed by two

of the organization’s internal groups,

often with different objectives. A

design / build team has to be

concerned with infrastructure

requirements, schedule, and

construction costs while facility

operations is focused more on

availability and operating

expenditures.

All of the above are a part of the

company’s holistic objectives,

although in the absence of common

leadership or synergy between the

groups, often the design / build

objectives don’t take into account

those of facility operations.

Often missed during commissioning

is the opportunity for facility

operations to contribute and better

understand sequences, consequences

of outages, and other attributes of

the infrastructure by participating in

the full project lifecycle

commissioning process. Missing this

once-in-a-facility’s-lifetime opportunity

is an unfortunate and all too common

occurrence.

OPPORTUNITY

ABOUNDS

There are a number of specific areas

where operations stands to benefit

from participating in commissioning,

including:

• Sequence Optimization

• Equipment Familiarity

• Troubleshooting Techniques

• Resource Identification

• Cause and Effect Baseline

Knowledge

• Continuous Improvement

Commissioning begins in earnest

during the design phase with project

requirements review and participation

in commenting on the design itself.

This is a great time to engage

operations to provide initial input.

A critical aspect during this phase is

the Sequence of Operations (SoO)

development which will take into

consideration the facility’s operating

obligations. Having operators

comment on the SoO, and then

subsequently participate in the

validation testing, provides an

important opportunity for the team to

influence and truly understand the

design basis of the facility.

The inner workings and nuances of

equipment operation are never more

accessible than during start-up and

functional testing (commonly referred

to as Levels 3 and 4 of the

commissioning process). If planned

properly, operators can be scheduled

to participate in activities like chiller

control checkouts, manipulating

system flow, and electrical switching

evolutions.

Once these components and systems

are deemed operational and placed

in service, the equipment is

infrequently available for this type of

hands-on manipulation. By including

facility operations in testing, the

operators stand to better understand

the equipment for the purpose of

maintenance evolutions, future

problem identification, and

troubleshooting during emergency

situations. In instances where they

have not experienced this level of

familiarity, they are at a disadvantage

and forced to be tentative when they

are better served as decisive.

Speaking of troubleshooting, the

commissioning process typically

7X24 MAGAZINE SPRING 2015

by

Brian Durham
