Data centers are specialized critical facilities designed to

house dense collections of computing equipment: servers,

storage arrays, switches, routers, and related items. Data

centers range from small room-sized facilities with a total

electric load of some tens of kilowatts to very large,

purpose-built facilities and campuses dissipating tens of

megawatts. Conceptual designs and initial planning for

100 MW data centers are in progress.

Data centers typically incorporate a substantial collection

of electric power and cooling equipment. Nearly all data

centers are designed to supply continuous power and

cooling

1

and incorporate combinations of redundant

assets, standby equipment, and energy storage to achieve

this goal. A typical large data center includes:

• Redundant electrical distribution systems supplying

“dual cord” loads

• Dual cord computing equipment; so long as power is

available on either cord, the equipment will operate.

Normally power is provided to both cords.

• Standby diesel engine/generators and associated fuel

stores

• Uninterruptible Power Supplies (UPS) and associated

kinetic or electrochemical energy storage. UPS bridge

the gap between loss of utility power and availability of

power from standby generators.

• Redundant computer room air handlers

• Redundant water cooling towers and fans

• Looped water distribution piping designed to allow

isolation and repair of damaged components while

operating

• Redundant refrigeration assets (some modern data

centers reduce or eliminate mechanical refrigeration)

The purpose of these complex, highly redundant systems

is to increase the reliability of the data center. The owners

and users of the facility expect it to operate even if the

local electric utility experiences an outage, and during

extremes of hot or cold weather.

PRESENT DATA CENTER METRICS

Popular data center metrics include Power Utilization

Effectiveness (PUE) and the Tier Classification system, a

proprietary rating system developed and administered by

the Uptime Institute in the early 1990s.

PUE is related to efficiency; it is the ratio of total data

center electric load to the power consumed by computer

equipment. Power to drive refrigeration units, fans,

pumps, lights, and other non-computer loads increase

PUE. A smaller PUE is considered more desirable; a PUE

of 1 would seem to be the lower limit, but by reclaiming

heat rejected by computer loads it is theoretically possible

to operate facilities with PUEs less than 1.

The Tier classification system is a proprietary scoring

method administered by the Uptime Institute and certain

authorized parties. The Uptime Institute charges a fee to

award a “Tier rating” to any facility.

The Tier system is primarily a measure of system

redundancy, on a scale of Tier 1 to Tier 4. Tier 1 systems

have limited redundancy but typically incorporate a UPS

with a bypass path and a standby generator. Tier 2

systems incorporate redundant components, for example

multiple UPS modules, chillers, and standby generators. If

N units of each asset are required to serve the facility

load, N+1 or more are provided.

Tier 3 facilities incorporate dual power and cooling

pathways, and Tier 4 facilities provide still higher levels of

redundancy.

While the Uptime Institute claims that Tier levels are

associated with availability, analysis by MTech and others

2

,

3

have demonstrated that this is not the case. The claimed

availability levels for each Tier are the result of the

assumptions built into the system by the Uptime Institute

4

.

Most notably, both independent analyses conclude that

there is very little difference in availability between Tier 3

and Tier 4 facilities.

Even if the Tier system were an accurate predictor of

availability, it does not address reliability.

7X24 MAGAZINE SPRING 2015

by

Steve Fairfax
