exposures e.g. fire, flood, earthquake at once per 250

years each, means that external factors will limit the facility

to at best Class 0.75.

MTech’s fault tree analysis of electric and cooling systems

cannot determine Class ratings without important limits

and assumptions. Our studies have shown that so-called

preventive maintenance is a major, in some cases

dominant, cause of system failure. A realistic “budget” for

class rating a very high performance facility might include

the following terms:

Facility Power and Cooling Systems Unreliability: Class 0.5

Maintenance-induced Failures:

Class 0.5

Sum of fires, floods, other 250-year events:

Class 1

Facility Class rating:

Class 2

This example shows a useful property of Class ratings:

they can be added, so long as each term represents

separate threats to the facility.

Another useful attribute is comparison between facilities.

A Class 5 facility is 5 times more likely to fail than a Class

1 facility, and 10 times more likely to fail than a class 0.5

facility.

Reliability cannot be compared so easily. AC 5 facility has

95% reliability for one year, a Class 1 facility has 99%. The

difference in reliability is only 4%. It is tempting to say that

a Class 1 facility is five times more reliable than a Class 5

facility, but that is incorrect.

DETERMINING CRITICAL FACILITY CLASS

Calculation with fault tree analysis has many useful

attributes, but is not the only way to predict or measure

critical facility Class. Reliability block diagrams, when used

appropriately, can perform similar calculations.

5

Measurement and observation may be used. A single

facility that operates for some years without any failures

might be tempted to claim “Class 0” performance, but

would risk rambunctious skepticism from informed

customers and damaged credibility. A more defensible

and conservative approach would be to estimate or

calculate the expected Class of the facility, and then use

statistical analysis to show that the years of zero downtime

are consistent with those claims within a given level of

statistical confidence.

Owners and operators of large fleets of data centers can

collect and publish data supporting Class ratings of their

entire fleet. A co-location provider who could offer

potential customers evidence of fleet Class performance

along with best and worse-case facilities in the fleet would

have a significant competitive advantage over a single

facility owner, who must collect their data much more

slowly.

Original equipment manufacturers can also employ Class

ratings, so long as they carefully define the assumptions

and limits of the claim. MTech’s client Active Power

recently published a white paper showing that the

unreliability for the CleanSource 750HD UPS with

extended runtime was 0.36% for short outages (less than

10 seconds.) That claim might be expressed as “The

CleanSource 750HD provides a Class 0.5 component for

critical facility electric power systems subjected to 1 short

outage per year.” Since there is no allowance for

scheduled maintenance in the 0.36% figure; Class 0.5 is

offered as a likely example.

An important component of Class rating is the frequency

of demands placed upon the system. Demand failures are

events that require standby systems to operate, or active

systems to change operating state, often by switching. If a

standby diesel/generator set has a 1% probability of not

starting when utility power fails, a facility with a single

generator cannot achieve Class 10 performance if there

are 10 or more utility outages per year. In a highly reliable

urban network distribution system, it is entirely possible to

support a claim of Class 10 performance with no standby

generator at all.

A credible class rating must disclose all assumptions and

data used to produce the claim, including the frequency

and duration of utility outages, assumptions about on-site

and off-site fuel supplies, allowance for failures produced

by maintenance and other sources of human error, and

exclusions of certain events such as major storms,

earthquakes, or fires.

MTech proposes the Class metric as an aid for discussion

and improvement of mission critical facility performance. It

can be used in design, operation, maintenance, and

failure analysis. Class, the probability of failure over a full

year of operation, is related to but distinct from reliability.

MTech makes no claim of intellectual property rights to

the term Class or its use to characterize the performance

of critical facilities. We encourage the use, discussion,

criticism, and debate of Class as a critical facility

performance metric. Those who wish to use Class to

characterize their facilities should describe in detail the

methods, assumptions, and limits that were used to

produce the claim.
